Mod. L-ACT

Refrigerating dryers

ALUMINIUM TECHNOLOGIES DIRECT TO ENERGY SAVING
LA PADANA has increased it’s range of compressed air dryers with the introduction of the new ACT range (Aluminium Cooling Technologies). This high efficiently cooling module has a direct effect on reducing energy consumption and pressure drop. The main advantages are: ñ Low pressure drop even with load variances; ñ Constant pressure DewPoint with differing load conditions. The components of the ACT range from refrigerant to materials of construction have been selected with maximum respect for the environment and their ability to be recycled.

CONTROL PANEL

Operation of the dryer is monitored by a digital thermometer in the control panel. The DMC20 electronic controller is fitted as standard to models ACT 900 - 1500 and as an option to models ACT 180 - 720.

“HOT GAS” BY-PASS VALVE

The precise and accurate hot gas by-pass valve, which prevents the formation of ice inside the evaporator at any load condition, is a recent development unavailable in the past. The valve is set during final test and no further adjustments are necessary. There is only one model of valve for each refrigerant used.


CONDENSATE DRAIN

All models are fitted with a Cimed electronic drain. Discharge and pause times are adjustable. A zero loss drain is available as an option.
